Must EH55-H3KRSL (EH55-H3KRS) Rack-mount Online UPS 3KVA/3KW

Must EH55-H3KRSL (EH55-H3KRS) Rack-mount Online UPS 3KVA/3KW
Upcoming
Share:
Must EH55-H3KRSL (EH55-H3KRS) Rack-mount Online UPS 3KVA/3KW
  • Product id:  510
  • Brand: MUST
  • Model: EH55-H3KRSL
  • Dimensions: 43.80cm x 50.40cm x 8.80cm
  • SKU: MSTEH3KRSL
Based on 0 reviews. - Write a review
WhatsApp Inquiry

Upcoming

Key Features

  • 3KVA / 3KW True Online Double Conversion with Pure Sine Wave & 0ms transfer time
  • Rack-mount Long-run version with external battery support (96V DC)
  • Wide input range 110–300VAC, Power Factor 1.0, efficiency up to 95.5%
  • DSP control, LCD + LEDs, USB/RS-232 + optional SNMP, adjustable charging current
View more info

Please confirm availability before completing your purchase by calling us.

The actual product may vary in size, color, and layout compared to the website display images. Claims will not be accepted for image discrepancies.

We reserve the right to change the price of any product at any time due to the volatile nature of technology prices.

We cannot guarantee that the information on this page is 100% accurate. Trende Bangladesh is not responsible for any results obtained from using this information.

Specification
Battery
Battery Quantity External (Long-run design)
Battery Voltage 96V DC
General
UPS Type True Online Double Conversion (High Frequency, DSP Controlled)
General Information
Rated Power 3KW (Power Factor 1.0)
Capacity 3KVA
Input Voltage 208 / 220 / 230 / 240 VAC
Output Voltage 208 / 220 / 230 / 240 VAC
Backup Time Depends on external battery capacity
Protection
Overheat Protection Yes
Optical Interface
Connector Type L+N+PE
Ports & Interfaces
USB Port Yes (USB + RS-232)
LED Indicator Yes (LCD Display + 4 LEDs)
Electrical Specifications
Efficiency Up to 95.5% (AC Mode @ 220VAC)
Output Frequency Online mode follows mains; Battery mode 50/60 Hz ±0.1%
Transfer Time 0 ms (AC to Battery), 4 ms (to Bypass)
Features
Auto Restart Yes
AVR Support Not required (True Online Double Conversion)
Cold Start Yes (Battery start without AC input)
Overload Protection Yes (timed levels for AC & Battery mode)
Short Circuit Protection Yes
Silent Mode Intelligent fan control (Noise ≤45 dB)
Smart Charging Yes (Adjustable charging current)
Surge Protection Yes
Interface
AC Output Port Terminal Block (L+N+PE) + Sockets
DC Output Port External Battery Terminals
PoE Output No
Power Button Yes
Power
Battery Capacity N/A
Waveform Type Pure Sine Wave
Physical Specification
Color Black
Dimensions Approx. 438 × 88 × 504 mm (W × H × D) – Standard Rack
Connectivity & Compatibility
Battery Type Lead-Acid (External)
Physical Design & Dimensions
Material Metal Housing
Weight Approx. 11 – 22 kg (without external batteries)
Battery & Power
Overcharge Protection Yes
Warranty & Support
Warranty 1 Year Official Warranty
Description
Must EH55-H3KRSL 3KVA/3KW true online double conversion rack-mount long-run UPS with pure sine wave output, 0ms transfer time, external 96V DC battery support and up to 95.5% efficiency, ideal for server racks and network cabinets.
