IP-COM G1128P-24-250W 24-Port Gigabit PoE Unmanaged Switch
A growing business network needs more than just available Ethernet ports. When IP cameras, wireless access points and other network devices are connected across multiple rooms or floors, choosing the right switch can make installation and future expansion much easier.
The IP-COM G1128P-24-250W 26GE+2SFP Ethernet Unmanaged Switch with 24-Port PoE is built for business networks that need Gigabit connectivity and Power over Ethernet in one device. It offers 24 Gigabit PoE ports, 2 additional Gigabit RJ45 uplinks and 2 Gigabit SFP interfaces, making it a practical networking solution for offices, hotels, schools and commercial CCTV installations.
Gigabit Speed Across All 24 PoE Ports
Unlike Fast Ethernet PoE switches that limit connected devices to 100Mbps, the IP-COM G1128P-24-250W provides 24 × 10/100/1000Mbps RJ45 PoE ports.
This allows compatible IP cameras, wireless access points and other PoE-enabled devices to connect using Gigabit Ethernet while receiving power through the same cable.
The switch supports IEEE 802.3af and IEEE 802.3at PoE standards, with automatic detection of compatible powered devices. Each PoE port can deliver up to 30W, subject to the total available PoE power budget.
For offices running several wireless access points or CCTV systems using high-resolution IP cameras, having Gigabit PoE ports provides greater network flexibility than a standard 100Mbps PoE switch.
230W Available PoE Power with a 250W Power Rating
Power distribution is one of the most important considerations when installing multiple PoE devices.
The IP-COM G1128P-24-250W has a maximum total power consumption rating of 250W, while its usable PoE power budget is 230W.
For example, if 20 compatible cameras each require 8W, their combined power demand would be approximately 160W. This fits within the switch's available PoE budget, leaving capacity for other compatible devices.
However, connecting 24 devices that each require 30W would exceed the total PoE budget. Always check the maximum power requirements of connected equipment before finalizing an installation.
Four Network Modes for Different Installation Needs
One useful feature of this IP-COM unmanaged PoE switch is its four-position hardware mode selector. Instead of configuring advanced software settings, installers can select an operating mode according to the network layout.
Standard Mode: All ports communicate normally, making it suitable for everyday office networking and CCTV connections.
Priority Mode: Ports 1–8 receive higher forwarding priority, which can help reduce packet loss and congestion for important connected devices when the network becomes busy.
Extend Mode: Ports 17–24 support transmission distances of up to 250 meters under suitable installation conditions. This can be useful when IP cameras are installed farther from the main networking cabinet.
VLAN Mode: PoE ports 1–24 are isolated from one another while retaining communication with the uplink interfaces. This helps reduce unwanted traffic between connected devices and can limit certain broadcast-related network problems.
These four operating modes provide useful flexibility without turning the device into a fully managed network switch.
More Connection Options with 26GE + 2SFP Interfaces
The G1128P-24-250W offers a total of 26 Gigabit RJ45 interfaces and 2 Gigabit SFP slots.
Ports 1–24 are designed for PoE-powered equipment, while ports 25–26 provide dedicated Gigabit Ethernet uplink connections.
The two 1G SFP interfaces support compatible fiber modules, making the switch useful when connecting network equipment between floors, buildings or distribution points through fiber cabling.
With 56Gbps switching capacity, 41.7Mpps packet forwarding performance and store-and-forward switching, the device is designed to handle traffic across its Gigabit interfaces.
Professional Hardware for Business Networking
The IP-COM G1128P-24-250W uses a durable metal enclosure with dimensions of 440 × 178 × 44mm. It supports rack, desktop and wall mounting, allowing installers to fit the device into different networking environments.
A built-in cooling fan helps manage operating temperatures during use. The switch also features LED indicators for power, network link/activity and PoE power status.
For additional electrical protection, IP-COM specifies 6kV lightning protection for the Ethernet ports and power interface. Proper grounding and suitable external surge protection may still be necessary depending on the installation environment.
The switch operates using AC 100–240V, 50/60Hz input and is designed for operating temperatures from 0°C to 45°C.
Where This IP-COM PoE Switch Makes Sense
The IP-COM G1128P-24-250W 24 Port Gigabit PoE Switch is suitable for commercial installations where multiple network devices need both reliable Ethernet connectivity and PoE power.
Typical applications include office CCTV networks, hotels, educational institutions, warehouses, shopping complexes, multi-floor business buildings and wireless access point installations.
For users who need advanced VLAN configuration, remote monitoring, detailed port management or cloud-based control, a managed PoE switch would be a better choice. This model is an unmanaged switch with hardware-selectable operating modes.
IP-COM G1128P-24-250W Price in Bangladesh
The IP-COM G1128P-24-250W price in Bangladesh is ৳13,000 at Trende Bangladesh, with a regular listed price of ৳14,000.
If you are looking for an IP-COM 24 port PoE switch price in BD, this model offers Gigabit PoE connectivity, 2 SFP uplinks and useful CCTV networking features at its current listed price.
Check the IP-COM G1128P-24-250W product page for updated pricing and availability.
